2023 Ford F-150 XL - Specs & Features

Select a trim
Starting MSRP
$41,530
Overview
Overview
Engine TypeFlex-fuel (FFV)
Transmission10-speed shiftable automatic
Drive TypeRear wheel drive
CylindersV6
Total Seating6
Basic Warranty3 yr./ 36,000 mi.
Fuel & MPG
Fuel & MPG
Fuel typeFlex-fuel (unleaded/E85)
EPA city/highway MPG19/24 MPG
EPA combined MPG21 MPG
Range in miles (city/hwy)494.0/624.0 mi.
Fuel tank capacity26.0 gal.
Engine
Engine
Base engine size3.3 L
CylindersV6
Base engine typeFlex-fuel (FFV)
Horsepower290 hp @ 6,500 rpm
Torque265 lb-ft @ 4,000 rpm
Valves24
Cam typeDouble overhead cam (DOHC)
Valve timingVariable
Direct injectionStandard
Towing & Hauling
Towing & Hauling
Max Towing Capacity14,000 lbs.
Max Payload Capacity1,785 lbs.
Drivetrain
Drivetrain
Transmission10-speed shiftable automatic
Drive typeRear wheel drive
Suspension
Suspension
Front independent suspensionStandard
Stabilizer bar stabilizer barStandard
Dimensions
Dimensions
Length231.7 in.
Overall width with mirrors95.7 in.
Overall width without mirrors79.9 in.
Height75.6 in.
Wheelbase145.4 in.
Bed length67.1 in.
Turning circle47.8 ft.
Ground clearance8.5 in.
Angle of approach21.8 degrees
Angle of departure22.9 degrees
Curb weight4,465 lbs.
Maximum towing capacity14,000 lbs.
Maximum payload1,785 lbs.
Gross weight6,250 lbs.
Country of final assemblyUnited States
Colors
Colors
Exterior Colors
  • Area 51 Blue
  • Hot Pepper Red Tinted Clearcoat Metallic
  • Atlas Blue Metallic
  • Race Red
  • Stone Gray Metallic
  • Avalanche
  • Antimatter Blue Metallic
  • Agate Black Metallic
  • Iconic Silver Metallic
  • Rapid Red Metallic Tinted Clearcoat
  • Carbonized Gray Metallic
  • Oxford White
Interior Colors
  • Black/Medium Dark Slate, cloth
  • Black/Medium Dark Slate, vinyl
Front Seat Dimensions
Front Seat Dimensions
Front head room40.8 in.
Front leg room43.9 in.
Front shoulder room66.7 in.
Front hip room62.5 in.
ClothStandard
40-20-40 split bench front seatsStandard
4-way manual driver seat adjustmentsStandard
4-way manual passenger seat adjustmentStandard
Rear Seat Dimensions
Rear Seat Dimensions
Rear head room40.4 in.
Rear leg room43.6 in.
Rear shoulder room66.0 in.
Rear hip room62.6 in.
Split-folding rear seatbackStandard
Safety
Safety
Lane departure warning accident avoidance systemStandard
Lane keep assistStandard
Pre-collision safety systemStandard
Post-collision safety systemStandard
Dual front side-mounted airbagsStandard
Front and rear head airbagsStandard
Passenger airbag occupant sensing deactivationStandard
Stability controlStandard
Traction controlStandard
Child seat anchorsStandard
Rear door child safety locksStandard
4-wheel ABSStandard
Front and rear ventilated disc brakesStandard
Emergency braking preparationStandard
Emergency braking assistStandard
Tire pressure monitoringStandard
Dusk sensing headlampsStandard
Auto delay off headlampsStandard
Daytime running lightsStandard
3 front headrestsStandard
Front height adjustable headrestsStandard
3 rear headrestsStandard
Rear height adjustable headrestsStandard
Front center 3-point beltStandard
Rear center 3-point beltStandard
Remote anti-theft alarm systemStandard
Engine immobilizerStandard
In-Car Entertainment
In-Car Entertainment
8.0" infotainment display sizeStandard
AM/FM stereoStandard
6 total speakersStandard
Wireless Android Auto/Apple CarPlayStandard
USB connectionStandard
USB with external media controlStandard
Power Feature
Power Feature
2 one-touch power windowsStandard
Remote keyless power door locksStandard
Heated mirrorsStandard
Comfort & Convenience
Comfort & Convenience
Tilt and telescopic steering wheelStandard
Audio and cruise controls on steering wheelStandard
Power steeringStandard
Rear view cameraStandard
Rear parking sensorsStandard
Cruise controlStandard
Front and rear door pocketsStandard
Single zone front air conditioningStandard
Passenger vanity mirrorStandard
Instrumentation
Instrumentation
Trip computerStandard
CompassStandard
External temperature displayStandard
TachometerStandard
ClockStandard
Tires & Wheels
Tires & Wheels
Painted steel wheelsStandard
17 in. wheelsStandard
All season tiresStandard
245/70R17 tiresStandard
Fullsize non-matching spare tireStandard
Underbody mounted spare tireStandard
Telematics
Telematics
Airbag Deployment NotificationStandard
Destination guidance (also Turn-by-Turn Navigation)Standard
Destination DownloadStandard
Warranty
Warranty
Basic3 yr./ 36,000 mi.
Drivetrain5 yr./ 60,000 mi.
Rust5 yr./ unlimited mi.
Roadside assistance5 yr./ 60,000 mi.
Mechanical Options
Mechanical Options
3.5L EcoBoost V6 +$2,735
3.5L PowerBoost Full Hybrid V6 +$4,495
2.7L EcoBoost V6 +$1,285
5.0L V8 w/Flex-Fuel Capability +$2,335
E-Locking 3.55 Axle +$470
E-Locking 3.31 Axle +$420
E-Locking 3.73 Axle +$570
3.73 Non-Limited Slip Axle +$80
Extended Range 36 Gallon Fuel Tank +$445
Auto Start-Stop Removal -$50
Engine Block Heater +$90
Packages
Packages
Trailer Tow Package +$1,325
Max Trailer Tow Package +$2,215
Max Trailer Tow Package +$2,215
STX Black Appearance Package +$3,370
Equipment Group 102A +$385
XL Chrome Appearance Package +$395
Bed Utility Package +$695
Equipment Group 101A +$0
2.7L V6 EcoBoost Payload Package +$750
STX Appearance Package +$2,585
Safety & Security Options
Safety & Security Options
Co-Pilot 360 2.0 +$655
Backup Alarm System (Fleet) +$145
Daytime Running Lamps (Fleet) +$45
Interior Options
Interior Options
Carpeting and Floor Mats +$145
Ash Cup w/Lighter +$80
SYNC 4 Mid w/Digital Assistant +$325
Sport Cloth 40/Console/40 Front Seat +$295
Trailer Brake Controller +$275
Cloth 40/Console/40 Front Seat +$295
8-Way Power Driver Seat (Fleet) +$350
110V/400W Outlet +$340
Ash Cup w/Coin Holder +$45
Commercial Roadside Assistance Kit +$230
Keyless Entry Keypad +$130
40/20/40 Removable Cup Tray +$60
Interior Work Surface +$195
In-Vehicle Safe by Console Vault +$400
Tray Style Rubber Floor Liners +$160
Roadside Assistance Kit w/Ford Logo +$70
First Aid Kit w/Ford Logo +$50
Tray Style Rubber Floor Liners w/Carpeted Matching Floor Mats +$200
Exterior Options
Exterior Options
Front and Rear Chrome Bumpers (Fleet) +$175
Rear Privacy Glass +$320
BoxLink +$80
Class IV Trailer Hitch +$315
Manual-Folding, Dual Power Glass Heated Sideview Mirrors +$305
Onboard Scales w/Smart Hitch +$650
Black Platform Running Boards +$250
Premium Aluminum Crossbed Toolbox by Weather Guard +$950
Hidden Lug Wheel Lock Kit +$75
LED Side-Mirror Spotlights +$175
Exposed Lug Wheel Lock Kit +$75
Aluminum Crossbed Toolbox by Weather Guard +$950
Amber LED Warning Strobes by Sound Off Signal (Fleet) +$600
Stowable Bed Ramps +$595
Horizontal Bed Cargo Net +$75
Vertical Bed Cargo Net +$75
Rear Window Defroster +$220
Retractable Tonneau Pickup Box Cover +$2,200
Front & Rear Molded Splash Guards +$235
Sportliner by BedRug +$550
Pro Power Onboard - 7.2kW +$750
Amber/White LED Warning Strobes by Sound Off Signal (Fleet) +$600
Chrome Exhaust Tips +$105
Bed Tray +$285
Bed Divider +$410
Bed Tailgate Lock by McGard +$70
Fog Lamps w/Black Bezels +$140
Pivot Storage Box +$290
Manual-Folding, Dual Manual Glass Mirrors +$395
Black Tailgate Decals +$90
Removable Bed Mat +$210
Tough Bed Spray-In Bedliner +$595
LT245/70R17E Black Side Wall All-Terrain Tires (Fleet) +$295
Plastic Drop-In Bedliner +$350
20" Six-Spoke Machined Aluminum Wheels w/Magnetic Painted Pockets +$1,225
Class IV Trailer Hitch +$315
Soft Folding Tonneau Pickup Box Cover +$590
Front License Plate Bracket +$0
Hard Folding Tonneau Pickup Box Cover +$1,200
