Used 2016 Ford F-350 Super Duty XL - Specs & Features

Starting MSRP
$36,880
Overview
Overview
Engine TypeFlex-fuel (FFV)
Transmission6-speed shiftable automatic
Drive TypeRear wheel drive
CylindersV8
Total Seating6
Basic Warranty3 yr./ 36,000 mi.
Fuel & MPG
Fuel & MPG
Fuel typeFlex-fuel (unleaded/E85)
Range in miles (city/hwy)0/0 mi.
Fuel tank capacity35.0 gal.
Engine
Engine
Base engine size6.2 L
CylindersV8
Base engine typeFlex-fuel (FFV)
Horsepower385 hp @ 5,500 rpm
Torque405 lb-ft @ 4,500 rpm
Valves16
Cam typeSingle overhead cam (SOHC)
Valve timingVariable
Towing & Hauling
Towing & Hauling
Max Towing Capacity14,000 lbs.
Max Payload Capacity3,450 lbs.
Drivetrain
Drivetrain
Transmission6-speed shiftable automatic
Drive typeRear wheel drive
Advertisement
See Offers Near Columbus, OH
Check out current offers on the Ford F-350 Super Duty
View Offers
Ford.com
Suspension
Suspension
Front independent suspensionStandard
Stabilizer bar stabilizer barStandard
Dimensions
Dimensions
Length246.8 in.
Overall width with mirrors104.9 in.
Overall width without mirrors79.9 in.
Height77.2 in.
Wheelbase156.2 in.
Bed length81.8 in.
EPA interior volume133.5 cu.ft.
Ground clearance8.5 in.
Angle of approach18.8 degrees
Angle of departure16.4 degrees
Curb weight6,481 lbs.
Maximum towing capacity14,000 lbs.
Maximum payload3,450 lbs.
Gross weight10,000 lbs.
Country of final assemblyUnited States
Colors
Colors
Exterior Colors
  • Green Gem Metallic
  • Blue Jeans Metallic
  • Oxford White
  • Magnetic Metallic
  • Ingot Silver Metallic
  • Shadow Black
  • Caribou Metallic
  • Race Red
Interior Colors
  • Steel, cloth
  • Steel, vinyl
Front Seat Dimensions
Front Seat Dimensions
Front head room40.7 in.
Front leg room41.1 in.
Front shoulder room68.0 in.
Front hip room67.6 in.
VinylStandard
40-20-40 split bench front seatsStandard
4-way manual driver seat adjustmentsStandard
Driver seat with manual adjustable lumbar supportStandard
4-way manual passenger seat adjustmentStandard
Rear Seat Dimensions
Rear Seat Dimensions
Rear head room40.8 in.
Rear leg room42.1 in.
Rear shoulder room68.0 in.
Rear hip room67.6 in.
Split-folding rear seatbackStandard
Safety
Safety
Post-collision safety systemStandard
Dual front side-mounted airbagsStandard
Front and rear head airbagsStandard
Stability controlStandard
Traction controlStandard
Child seat anchorsStandard
Rear door child safety locksStandard
4-wheel ABSStandard
Front and rear ventilated disc brakesStandard
Tire pressure monitoringStandard
3 front headrestsStandard
Front height adjustable headrestsStandard
3 rear headrestsStandard
Rear height adjustable headrestsStandard
Front center 3-point beltStandard
Rear center 3-point beltStandard
Engine immobilizerStandard
In-Car Entertainment
In-Car Entertainment
AM/FM stereoStandard
2 total speakersStandard
Mast antennaStandard
Power Feature
Power Feature
Heated mirrorsStandard
Comfort & Convenience
Comfort & Convenience
Tilt and telescopic steering wheelStandard
Power steeringStandard
Front cupholdersStandard
Front door pocketsStandard
Overhead console with storageStandard
Single zone front air conditioningStandard
Passenger vanity mirrorStandard
Instrumentation
Instrumentation
Trip computerStandard
External temperature displayStandard
TachometerStandard
ClockStandard
Tires & Wheels
Tires & Wheels
Painted steel wheelsStandard
Partial wheel coversStandard
17 in. wheelsStandard
All season tiresStandard
LT245/75R E tiresStandard
Fullsize matching spare tireStandard
Underbody mounted spare tireStandard
Warranty
Warranty
Basic3 yr./ 36,000 mi.
Drivetrain5 yr./ 60,000 mi.
Drivetrain5 yr./ 100,000 mi.
Rust5 yr./ unlimited mi.
Roadside assistance5 yr./ 60,000 mi.
Mechanical Options
Mechanical Options
Dual Alternators +$380
Engine Block Heater +$75
Extra Heavy-Duty 200 Amp Alternator +$75
Transmission Power Take-Off Provision +$280
6.7L Power Stroke Diesel V-8 +$8,480
TorqShift 6-Speed Automatic Transmission +$0
3.31 Axle Ratio Electronic Locking Rear Differential +$390
Engine Idle Shutdown +$250
TowCommand Integrated Trailer Brake Controller +$270
3.73 Axle Ratio Electronic Locking Rear Differential +$390
4.30 Axle Ratio Electronic Locking Rear Differential +$390
Remote Vehicle Start +$195
CNG/LPG Fuel Capable Engine +$315
Operator Commanded Regeneration (OCR) +$250
Packages
Packages
XL Value Package +$595
Camper Package +$160
XL Appearance Package +$945
Power Equipment Group +$1,105
Heavy Service Front Suspension Package +$125
10,000 lbs. GVWR Package +$0
5th Wheel/Gooseneck Hitch Prep Package +$370
Safety & Security Options
Safety & Security Options
Exterior Back-up Chime +$125
Interior Options
Interior Options
SYNC w/MyFord +$295
Rapid-Heat Supplemental Cab Heater +$250
Steering Wheel Audio Controls +$70
Cloth High Back Bucket Seats +$615
Cloth 40/20/40 Split Bench Front Seat +$315
Exterior Options
Exterior Options
Tailgate Step +$375
Tough Bed Spray-In Bedliner +$495
Roof Clearance Lights +$55
Wheel Well Liner +$180
Drop-In Bedliner +$350
17" 6-Spoke Cast Aluminum Wheels w/Bright Hub Covers/Center Ornaments +$600
LT245/75R17E All-Terrain BSW Tires +$165
LT265/70R17E All-Terrain OWL Tires +$455
Ford Work Solutions Crew Chief Telematics by Telogis +$800
18" Argent Painted Steel Wheels w/Painted Hub Covers/Center Ornaments +$455
6" Angular Black Molded-In-Color Running Boards +$370
LT275/65R18E All-Season BSW Tires +$0
Ford Work Solutions Cable Lock by Master Lock +$120
Bed Mat +$135
Roll-Up Tonneau Cover +$330
Front and Rear Splash Guards/Mud Flaps +$130
Gooseneck Hitch Kit +$250
