features & specs
2001 Subaru Legacy
2001 Subaru Legacy
| OVERVIEW | |||
|---|---|---|---|
| Combined MPG | 21 | 21 | 21 |
| Transmission | 4-speed automatic | 4-speed automatic | 4-speed automatic |
| Basic Warranty | 3 yr./ 36000 mi. | 3 yr./ 36000 mi. | 3 yr./ 36000 mi. |
| Base Engine Type | gas | gas | gas |
| Total Seating | 5 | 5 | 5 |
| Cylinders | flat 4 | flat 4 | flat 4 |
| Drivetrain | all wheel drive | all wheel drive | all wheel drive |
| COLORS | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| Exterior Colors | | | |
| Interior Colors | | | |
| Safety | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| 2 front headrests | true | true | true |
| 3 rear headrests | true | true | true |
| child seat anchors | true | true | true |
| daytime running lights | true | true | true |
| electronic brakeforce distribution | true | true | true |
| front seatbelt pretensioners | true | true | true |
| 4-wheel ABS | true | true | true |
| Rear center 3-point belt | true | true | true |
| Rear door child safety locks | true | true | true |
| Ventilated front disc / solid rear disc brakes | true | true | true |
| front fog/driving lights | false | true | true |
| dual front side-mounted airbags | false | false | true |
| Comfort & Convenience | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| cruise control | true | true | true |
| front and rear cupholders | true | true | true |
| front door pockets | true | true | true |
| power steering | true | true | true |
| remote trunk release | true | true | true |
| tilt-adjustable steering wheel | true | true | true |
| trunk light | true | true | true |
| Air conditioning | true | true | true |
| leather steering wheel | false | true | true |
| leather trim on shift knob | false | true | true |
| wood trim on dash | false | true | true |
| wood trim on doors | false | true | true |
| Fuel & MPG | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| Combined MPG | 21 | 21 | 21 |
| EPA mileage est. (city/hwy) | 19/25 mpg | 19/25 mpg | 19/25 mpg |
| Fuel tank capacity | 16.9 gal. | 16.9 gal. | 16.9 gal. |
| Fuel type | regular unleaded | regular unleaded | regular unleaded |
| range in miles (city/hwy) | 321.1/422.5 mi. | 321.1/422.5 mi. | 321.1/422.5 mi. |
| Engine | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| Base engine size | 2.5 L | 2.5 L | 2.5 L |
| Base engine type | gas | gas | gas |
| Cam type | Single overhead cam (SOHC) | Single overhead cam (SOHC) | Single overhead cam (SOHC) |
| Cylinders | flat 4 | flat 4 | flat 4 |
| Horsepower | 165 hp @ 5600 rpm | 165 hp @ 5600 rpm | 165 hp @ 5600 rpm |
| Torque | 166 ft-lbs. @ 4000 rpm | 166 ft-lbs. @ 4000 rpm | 166 ft-lbs. @ 4000 rpm |
| Valves | 16 | 16 | 16 |
| Measurements | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| Curb weight | 3255 lbs. | 3410 lbs. | 3435 lbs. |
| Ground clearance | 6.1 in. | 6.1 in. | 6.1 in. |
| Height | 55.7 in. | 55.7 in. | 55.7 in. |
| Length | 184.4 in. | 184.4 in. | 184.4 in. |
| Maximum towing capacity | 2000 lbs. | 2000 lbs. | 2000 lbs. |
| wheelbase | 104.3 in. | 104.3 in. | 104.3 in. |
| Width | 68.7 in. | 68.7 in. | 68.7 in. |
| Turning circle | 35.4 ft. | 35.4 ft. | 35.4 ft. |
| Front Seats | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| bucket front seats | true | true | true |
| cloth | true | true | false |
| front headroom | 38.9 in. | 38.1 in. | 38.1 in. |
| front hiproom | 51.3 in. | 51.3 in. | 51.3 in. |
| front legroom | 43.3 in. | 43.3 in. | 43.3 in. |
| Front shoulder room | 53.9 in. | 53.9 in. | 53.9 in. |
| 6-way power driver seat | false | true | true |
| Driver seat with manual adjustable lumbar support | false | true | true |
| leather | false | false | true |
| Rear Seats | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| pass-thru center armrest | true | true | true |
| rear ventilation ducts | true | true | true |
| rear headroom | 36.6 in. | 36.6 in. | 36.6 in. |
| rear hiproom | 51.9 in. | 51.9 in. | 51.9 in. |
| rear legroom | 34.2 in. | 34.2 in. | 34.2 in. |
| Rear shoulder room | 53.6 in. | 53.6 in. | 53.6 in. |
| Drive Train | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| full time 4WD | true | true | true |
| viscous center differential | true | false | false |
| Center limited slip differential | true | false | false |
| Drive type | all wheel drive | all wheel drive | all wheel drive |
| Transmission | 5-speed manual | 4-speed automatic | 4-speed automatic |
| mechanical center differential | false | true | true |
| Center and rear limited slip differential | false | true | true |
| Power Features | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| 1 one-touch power window | true | true | true |
| power door locks | true | false | false |
| Heated mirrors | true | true | true |
| Power mirrors | true | true | true |
| remote keyless power door locks | false | true | true |
| Instrumentation | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| clock | true | true | true |
| external temperature display | true | true | true |
| low fuel level warning | true | true | true |
| tachometer | true | true | true |
| Suspension | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| four-wheel independent suspension | true | true | true |
| In-Car Entertainment | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| 4 total speakers | true | true | false |
| AM/FM stereo | true | true | true |
| element antenna | false | true | true |
| 6 total speakers | false | false | true |
| Warranty | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| Basic | 3 yr./ 36000 mi. | 3 yr./ 36000 mi. | 3 yr./ 36000 mi. |
| powertrain | 5 yr./ 60000 mi. | 5 yr./ 60000 mi. | 5 yr./ 60000 mi. |
| Tires and Wheels | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| full wheel covers | true | false | false |
| steel wheels | true | false | false |
| 15-in. wheels | true | false | false |
| all-season tires | true | true | true |
| P205/60R H tires | true | false | false |
| alloy wheels | false | true | true |
| 16-in. wheels | false | true | true |
| P205/55R H tires | false | true | true |
| Interior Options | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| Air Filtration System | true | true | true |
| Leather Shift Knob | true | false | false |
| Electrochromic Mirror with Compass | true | true | true |
| Illuminated Vanity Mirror/Visor | true | false | false |
| Carpeted Floor Covers (Gray) | true | true | true |
| CD Player (Mechanical) | true | false | false |
| Woodgrained Patterned Trim | true | true | true |
| Popular Equipment Group 4 (Gray) | true | false | false |
| Trunk Net | true | true | true |
| Tweeter Kit (Pair) | true | true | false |
| Upgraded Speakers | true | true | false |
| Subwoofer with Amplifier | true | true | true |
| 6-Disc CD Changer In-Dash | false | true | true |
| Popular Equipment Group 6 | false | true | true |
| Power Outlet | false | true | true |
| CD Player (Logic Control) | false | true | false |
| Exterior Options | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| 15" Painted Wheels and Attachment Set | true | false | false |
| Multi-Reflector Fog Lamps | true | false | false |
| Hood Deflector (Acrylic) | true | true | true |
| Rear Differential Protector | true | true | true |
| Body Colored Rear Spoiler | true | true | true |
| Brushed Aluminum Wheels and Attachment Set | true | false | false |
| Wheel Locks (Alloy Wheels) | true | true | true |
| Splash Guards | true | false | false |
| Popular Equipment Group 2 (Gray) | true | false | false |
| Moonroof Air Deflector | false | true | true |
| Packages | L AWD 4dr Sedan (2.5L 4cyl 5M) | GT AWD 4dr Sedan (2.5L 4cyl 4A) | GT Limited AWD 4dr Sedan (2.5L 4cyl 4A) |
|---|---|---|---|
| Premium Sound Package 1A | true | false | false |
| Premium Sound Package 1B | false | true | false |
| Premium Sound Package 2 | false | true | false |
| Premium Sound Package 3 | false | false | true |
