Used 2016 Mercedes-Benz Sprinter Worker Specs & Features

Overview
Overview
Starting MSRP
$32,495

Engine TypeDiesel
Transmission7-speed shiftable automatic
Drive TypeRear wheel drive
CylindersInline 4
Total Seating2
Basic Warranty3 yr./ 36,000 mi.
Fuel & MPG
Fuel & MPG
Fuel typeDiesel fuel
Range in miles (city/hwy)0/0 mi.
Fuel tank capacity24.5 gal.
Engine
Engine
Base engine size2.1 L
CylindersInline 4
Base engine typeDiesel
Horsepower161 hp @ 3,800 rpm
Torque265 lb-ft @ 1,400 rpm
Valves16
Cam typeDouble overhead cam (DOHC)
Direct injection (diesel)yes
Towing & Hauling
Towing & Hauling
Max Towing Capacity5,000 lbs.
Max Payload Capacity3,512 lbs.
Drivetrain
Drivetrain
Transmission7-speed shiftable automatic
Drive typeRear wheel drive
Suspension
Suspension
Front independent suspensionyes
Front and rear stabilizer baryes
Dimensions
Dimensions
Length233.3 in.
Overall width with mirrors95.5 in.
Overall width without mirrors79.7 in.
Height94.5 in.
Wheelbase144.3 in.
Cargo capacity, all seats in place319.1 cu.ft.
Maximum cargo capacity319.1 cu.ft.
Turning circle47.6 ft.
Ground clearance7.9 in.
Curb weight5,038 lbs.
Maximum towing capacity5,000 lbs.
Maximum payload3,512 lbs.
Gross weight8,550 lbs.
Colors
Colors
Exterior Colors
  • Arctic White
Interior Colors
  • Tunja Black Upholstery, cloth
Front Seat Dimensions
Front Seat Dimensions
Clothyes
Bucket front seatsyes
4-way manual driver seat adjustmentsyes
4-way manual passenger seat adjustmentyes
Safety
Safety
Dual front side-mounted airbagsyes
Front head airbagsyes
Passenger airbag occupant sensing deactivationyes
Stability controlyes
Traction controlyes
4-wheel ABSyes
Ventilated front disc / solid rear disc brakesyes
Emergency braking assistyes
Tire pressure monitoringyes
Daytime running lightsyes
Turn signal mirrorsyes
2 front headrestsyes
Engine immobilizeryes
In-Car Entertainment
In-Car Entertainment
AM/FM stereoyes
5 total speakersyes
USB connectionyes
Auxiliary audio inputyes
Speed sensitive volume controlyes
Power Feature
Power Feature
Remote keyless power door locksyes
Heated mirrorsyes
Comfort & Convenience
Comfort & Convenience
Tilt and telescopic steering wheelyes
Power steeringyes
Front cupholdersyes
Front door pocketsyes
Overhead console with storageyes
Single zone front air conditioningyes
Turn signal in mirrorsyes
Instrumentation
Instrumentation
External temperature displayyes
Tachometeryes
Clockyes
Tires & Wheels
Tires & Wheels
Painted steel wheelsyes
16 x 6.5 in. wheelsyes
All season tiresyes
LT245/75R16 tiresyes
Fullsize matching spare tireyes
Underbody mounted spare tireyes
Warranty
Warranty
Basic3 yr./ 36,000 mi.
Drivetrain5 yr./ 100,000 mi.
Rust5 yr./ 100,000 mi.
Mechanical Options
Mechanical Options
Fuel-Fired Heater Booster +$600
Packages
Packages
Overtime Package +$4,499
Utility Package +$2,999
Convenience Package +$1,499
Safety & Security Options
Safety & Security Options
Rear Backup Alarm +$88
Driver And Front Passenger Orange Seat Belts +$26
Interior Options
Interior Options
Half Height Load Compartment Trim +$179
Side Wall Paneling Full Hardboard +$394
Head Height Cargo Lashing Rails +$369
D-Ring Cargo Straps +$71
Floor Cargo Lashing Rails +$330
Cargo Partition +$256
Cargo Partition w/Window +$297
Cargo Straps/Lashing Rails +$92
Waist Height Cargo Lashing Rails +$246
Exterior Options
Exterior Options
Mounting Rails For Roof Rack +$266
M+S Tires +$123
Wheel Chocks +$31
Assist Handle w/Partition +$26
