Used 2016 Mercedes-Benz B-Class Electric Drive Specs & Features

Starting MSRP

Engine TypeElectric
Transmission1-speed direct drive
Drive TypeFront wheel drive
Total Seating5
Basic Warranty4 yr./ 50,000 mi.
Battery & Range
Battery & Range
Fuel typeElectric
EPA city/highway MPGeMPGe is the official metric that the EPA uses to measure the efficiency of alternative-fuel (including electric) vehicles. Just like regular MPG shows how far a car will travel on one gallon of gas, MPGe shows how far a vehicle will drive on 33.7 kWh of electricity — the energy equivalent of one gallon of gasoline.85/82 MPGe
EPA combined MPGeA combined total of 45% city MPGe + 55% highway MPGe84 MPGe
Base engine typeElectric
Horsepower177 hp @ 0 rpm
Torque251 lb-ft @ 0 rpm
Transmission1-speed direct drive
Drive typeFront wheel drive
Four-wheel independent suspensionyes
Length171.6 in.
Overall width with mirrors80.0 in.
Overall width without mirrors70.3 in.
Height56.6 in.
Wheelbase106.2 in.
EPA interior volume116.9 cu.ft.
Cargo capacity, all seats in place21.6 cu.ft.
Maximum cargo capacity51.4 cu.ft.
Turning circle36.0 ft.
Curb weight3,924 lbs.
Exterior Colors
  • designo Magno Mountain Grey (Matte)
  • Kryptonite Green Metallic
  • Mountain Grey Metallic
  • South Seas Blue Metallic
  • Cocoa Brown Metallic
  • Night Black
  • Cirrus White
  • Jupiter Red
  • Polar Silver Metallic
  • Cosmos Black Metallic
Interior Colors
  • Crystal Grey, leatherette
  • Cranberry Red, leather
  • Hazelnut Brown, leather
  • Black, leather
  • Sahara Beige, leatherette
  • Black, leatherette
Front Seat Dimensions
Front Seat Dimensions
Front head room55.6 in.
Front shoulder room55.6 in.
Front hip room52.4 in.
Bucket front seatsyes
10-way power driver seatyes
Height adjustable driver seatyes
Driver seat with power adjustable lumbar supportyes
10-way power passenger seatyes
Height adjustable passenger seatyes
Passenger seat with power adjustable lumbar supportyes
Rear Seat Dimensions
Rear Seat Dimensions
Rear head room54.4 in.
Rear shoulder room54.4 in.
Rear hip room47.1 in.
Split-folding rear seatbackyes
Folding with pass-thru center armrestyes
Pre-collision safety systemyes
Dual front side-mounted airbagsyes
Front and rear head airbagsyes
Passenger airbag occupant sensing deactivationyes
Stability controlyes
Traction controlyes
Child seat anchorsyes
Rear door child safety locksyes
4-wheel ABSyes
Brake dryingyes
Emergency braking preparationyes
Emergency braking assistyes
Tire pressure monitoringyes
Dusk sensing headlampsyes
Auto delay off headlampsyes
Daytime running lightsyes
Turn signal mirrorsyes
2 front headrestsyes
3 rear headrestsyes
Rear height adjustable headrestsyes
Rear center 3-point beltyes
Remote anti-theft alarm systemyes
Engine immobilizeryes
In-Car Entertainment
In-Car Entertainment
AM/FM stereoyes
USB connectionyes
Power Feature
Power Feature
4 one-touch power windowsyes
Hands-free entryyes
Heated mirrorsyes
Comfort & Convenience
Comfort & Convenience
Keyless ignitionyes
Tilt and telescopic steering wheelyes
Audio controls on steering wheelyes
Electric power steeringyes
Cruise controlyes
Front and rear cupholdersyes
Front and rear door pocketsyes
Front seatback storageyes
Leather steering wheelyes
Dual zone front climate controlyes
Rear ventilation ductsyes
Interior air filtrationyes
Turn signal in mirrorsyes
Trip computeryes
External temperature displayyes
Tires & Wheels
Tires & Wheels
Alloy wheelsyes
17 x 7.5 in. wheelsyes
225/45R17 tiresyes
Run flat tiresyes
Emergency Serviceyes
Airbag Deployment Notificationyes
Vehicle Alarm notificationyes
Stolen Vehicle Tracking/Assistanceyes
Roadside Assistanceyes
Concierge Serviceyes
Destination guidance (also Turn-by-Turn Navigation)yes
Destination Downloadyes
Basic4 yr./ 50,000 mi.
Drivetrain4 yr./ 50,000 mi.
Rust4 yr./ 50,000 mi.
Roadside4 yr./ 50,000 mi.
Multimedia Package +$2,480
Premium Package +$2,690
Interior Package +$1,825
Safety & Security Options
Safety & Security Options
Blind Spot Assist +$550
PARKTRONIC w/Active Parking Assist +$970
Rear View Camera +$460
Interior Options
Interior Options
Radar-Based Regenerative Braking w/Paddles +$350
Heated Front Seats +$580
Harman/kardon® LOGIC7 Sound System +$850
