Used 2020 Ford F-150 Specs & Features

Starting MSRP

Engine TypeGas
Transmission6-speed shiftable automatic
Drive TypeFour wheel drive
Combined MPG20 MPG
Total Seating6
Basic Warranty3 yr./ 36,000 mi.
Fuel & MPG
Fuel & MPG
Fuel typeRegular unleaded
EPA mileage est. (cty/hwy)18/23 MPG
Combined MPG20 MPG
Range in miles (cty/hwy)468.0/598.0 mi.
Fuel tank capacity26.0 gal.
Base engine size3.3 L
Base engine typeGas
Horsepower290 hp @ 6,500 rpm
Torque265 lb-ft @ 4,000 rpm
Cam typeDouble overhead cam (DOHC)
Valve timingVariable
Direct injectionyes
Towing & Hauling
Towing & Hauling
Max Towing Capacity12,700 lbs.
Max Payload Capacity1,680 lbs.
Transmission6-speed shiftable automatic
Drive typeFour wheel drive
Part time 4WDyes
Electronic hi-lo gear selectionyes
Automatic locking hubsyes
Front independent suspensionyes
Stabilizer bar stabilizer baryes
Length231.9 in.
Overall Width with Mirrors96.8 in.
Overall Width without Mirrors79.9 in.
Height77.2 in.
Wheel base145.0 in.
Bed Length5'7”
Ground clearance9.4 in.
Angle of approach25.5 degrees
Angle of departure26.0 degrees
Curb weight4,769 lbs.
Maximum towing capacity12,700 lbs.
Maximum payload1,680 lbs.
Gross weight6,500 lbs.
Exterior Colors
  • Oxford White/Magnetic Metallic
  • Rapid Red Metallic Tinted Clearcoat
  • Race Red/Magnetic Metallic
  • Blue Jeans Metallic/Magnetic Metallic
  • Agate Black/Magnetic Metallic
  • Velocity Blue Metallic/Magnetic Metallic
  • Iconic Silver Metallic
  • Stone Gray Metallic
  • Agate Black
  • Blue Jeans
  • Oxford White
  • Rapid Red Metallic Tinted Clearcoat/Magnetic Metallic
  • Lead Foot Gray
  • Race Red
  • Magma Red Metallic
  • Velocity Blue Metallic
  • Magnetic Metallic
  • Vermillion Red (Fleet)
  • School Bus Yellow (Fleet)
  • Yellow (Fleet)
  • Orange (Fleet)
  • Green (Fleet)
  • Abyss Gray Metallic
  • Iconic Silver Metallic/Magnetic Metallic
  • Silver Spruce Metallic
Interior Colors
  • Black, premium cloth
  • Medium Light Camel, cloth
  • Medium Earth Gray, cloth
Front Seat Dimensions
Front Seat Dimensions
Front head room40.8 in.
Front leg room43.9 in.
Front shoulder room66.7 in.
Front hip room62.5 in.
40-20-40 split bench front seatsyes
4 -way manual driver seat adjustmentsyes
Driver seat with manual adjustable lumbar supportyes
4 -way manual passenger seat adjustmentyes
Passenger seat with manual adjustable lumbar supportyes
Rear Seat Dimensions
Rear Seat Dimensions
Rear head room40.3 in.
Rear leg room43.6 in.
Rear shoulder room65.9 in.
Rear hip Room64.7 in.
Split-folding rear seatbackyes
Pre-collision safety systemyes
Post-collision safety systemyes
Dual front side-mounted airbagsyes
Front and rear head airbagsyes
Passenger airbag occupant sensing deactivationyes
Stability controlyes
Traction controlyes
Child seat anchorsyes
Rear door child safety locksyes
4-wheel ABSyes
Front and rear ventilated disc brakesyes
Emergency braking preparationyes
Emergency braking assistyes
Tire pressure monitoringyes
Dusk sensing headlampsyes
Auto delay off headlampsyes
Daytime running lightsyes
Front fog/driving lightsyes
3 front headrestsyes
3 rear headrestsyes
Rear height adjustable headrestsyes
Front center 3-point beltyes
Rear center 3-point beltyes
Remote anti-theft alarm systemyes
Engine immobilizeryes
In-Car Entertainment
In-Car Entertainment
AM/FM stereoyes
6 total speakersyes
USB connectionyes
USB with external media controlyes
Power Feature
Power Feature
2 one-touch power windowsyes
Digital keypad power door locksyes
Heated mirrorsyes
Comfort & Convenience
Comfort & Convenience
Tilt and telescopic steering wheelyes
Audio and cruise controls on steering wheelyes
Electric power steeringyes
Rear view camerayes
Cruise controlyes
Front cupholdersyes
Front seatback storageyes
Single zone front air conditioningyes
Dual vanity mirrorsyes
Trip computeryes
External temperature displayyes
Tires & Wheels
Tires & Wheels
Painted alloy wheelsyes
17 in. wheelsyes
All terrain tiresyes
265/70R17 tiresyes
Fullsize non-matching spare tireyes
Underbody mounted spare tireyes
Airbag Deployment Notificationyes
Destination guidance (also Turn-by-Turn Navigation)yes
Destination Downloadyes
Basic3 yr./ 36,000 mi.
Drivetrain5 yr./ 60,000 mi.
Rust5 yr./ unlimited mi.
Roadside5 yr./ 60,000 mi.
Mechanical Options
Mechanical Options
E-Locking 3.31 Axle +$420
E-Locking 3.73 Axle +$570
Extended Range 36 Gallon Fuel Tank +$445
E-Locking 3.55 Axle +$470
3.0L Power Stroke Turbo Diesel V6 +$4,995
3.5L Ecoboost V6 +$2,595
2.7L Ecoboost V6 +$995
5.0L V8 w/Flex-Fuel Capability +$1,995
Remote Start System +$195
Engine Block Heater +$90
XLT Special Edition Package +$1,995
2.7L V6 EcoBoost Payload Package +$750
XLT Special Edition Package - Graphic Delete +$0
FX4 Off-Road Package +$905
Trailer Tow Package +$995
Max Trailer Tow Package +$1,295
Smoker's Pack +$95
CNG/Propane Gaseous Engine Prep Pack +$315
XLT Chrome Appearance Package +$945
Equipment Group 301A +$1,150
Equipment Group 302A +$2,595
XLT Power Equipment Group Package +$475
Snow Plow Prep +$50
XLT Sport Appearance Package +$1,245
XLT Black Appearance Package +$1,195
Equipment Group 300A +$0
Safety & Security Options
Safety & Security Options
Blind Spot Information System w/Cross-Traffic Alert +$590
Inflatable Rear Safety Belts +$200
Reverse Sensing System +$275
Interior Options
Interior Options
110V/400W Outlet +$200
Black Vinyl Flooring +$0
Cloth 40/Console/40 Front Seat +$295
Cloth 40/Console/40 Front Seat +$295
Cloth 40/Console/40 Front Seat +$295
Voice-Activated Navigation System +$295
Trailer Brake Controller +$275
All Weather Rubber Floor Mats +$160
KICKER Subwoofer +$695
Exterior Options
Exterior Options
20" Chrome-Like PVD Wheels +$1,295
Pickup Box LED Lighting +$125
Manual-Folding, Dual Manual Glass Mirrors +$275
20" Six-Spoke Premium Painted Aluminum Wheels +$1,295
LT245/70R17E Black Side Wall All-Terrain Tires +$295
Class IV Trailer Hitch +$150
Manual-Folding, Dual Power Glass Heated Sideview Mirrors +$190
Wheel Well Liner +$180
Hard Folding Tonneau Pickup Box Cover +$995
Soft Folding Tonneau Pickup Box Cover +$525
Two-Tone Paint +$250
Plastic Drop-In Bedliner +$350
BoxLink +$80
Rear Window Defroster +$220
LT275/65R18C Outline White Lettering All-Terrain Tires +$295
Front License Plate Bracket +$0
Chrome Tubular Running Boards +$635
LED Side-Mirror Spotlights +$175
Twin Panel Moonroof +$1,495
Power Sliding Rear Window +$350
Foldable Pickup Box Bed Extender +$250
Box Side Steps +$325
Black Platform Running Boards +$250
Bed Divider +$295
Tough Bed Spray-In Bedliner +$595
Aluminum Crossbed Toolbox by Weather Guard +$575
Aluminum Crossbed Toolbox by Weather Guard +$790
Bed Ramps +$595
Tailgate Step w/Tailgate Lift Assist +$375
