Used 2020 Chevrolet Silverado 3500HD Work Truck Specs & Features

More about the 2020 Silverado 3500HD
Buy In-StoreBuy Online
More about the 2020 Silverado 3500HD
Buy In-StoreBuy Online
Overview
Overview
Starting MSRP
$36,500
Buy In-StoreBuy Online
Engine TypeGas
Transmission6-speed shiftable automatic
Drive TypeRear wheel drive
CylindersV8
Total Seating3
Basic Warranty3 yr./ 36,000 mi.
Fuel & MPG
Fuel & MPG
Fuel typeRegular unleaded
Range in miles (cty/hwy)0/0 mi.
Fuel tank capacity36.0 gal.
Engine
Engine
Base engine size6.6 L
CylindersV8
Base engine typeGas
Horsepower401 hp @ 5,200 rpm
Torque464 lb-ft @ 4,000 rpm
Valves16
Cam typeOverhead valves (OHV)
Valve timingVariable
Direct injectionyes
Towing & Hauling
Towing & Hauling
Max Towing Capacity20,000 lbs.
Max Payload Capacity7,442 lbs.
Drivetrain
Drivetrain
Transmission6-speed shiftable automatic
Drive typeRear wheel drive
Rear locking differentialyes
ad labelAd
Also Consider
8 Offers Near Ashburn, VA
Check out current offers on the Chevrolet Silverado HD
View Offers
Chevrolet.com
*The Manufacturer's Suggested Retail Price excludes destination freight charge, tax, title, license, dealer fees and optional equipment. Click here to see all Chevrolet vehicles' destination freight charges.
Suspension
Suspension
Front independent suspensionyes
Stabilizer bar stabilizer baryes
Dimensions
Dimensions
Length235.5 in.
Overall Width without Mirrors96.8 in.
Height80.2 in.
Wheel base141.6 in.
Bed Length8'2”
Turning circle46.9 ft.
Ground clearance10.5 in.
Curb weight6,520 lbs.
Maximum towing capacity20,000 lbs.
Maximum payload7,442 lbs.
Gross weight14,000 lbs.
Colors
Colors
Exterior Colors
  • Northsky Blue Metallic
  • Red Hot
  • Shadow Gray Metallic
  • Oxford Brown Metallic
  • Summit White
  • Black
  • Silver Ice Metallic
Interior Colors
  • Jet Black, vinyl
  • Jet Black, cloth
Front Seat Dimensions
Front Seat Dimensions
Front head room43.1 in.
Front leg room44.5 in.
Front shoulder room66.0 in.
Front hip room60.9 in.
Vinylyes
40-20-40 split bench front seatsyes
4 -way manual driver seat adjustmentsyes
4 -way manual passenger seat adjustmentyes
Safety
Safety
Dual front side-mounted airbagsyes
Front head airbagsyes
Passenger airbag occupant sensing deactivationyes
Stability controlyes
Traction controlyes
Child seat anchorsyes
4-wheel ABSyes
Front and rear ventilated disc brakesyes
Emergency braking assistyes
Tire pressure monitoringyes
Dusk sensing headlampsyes
Auto delay off headlampsyes
Daytime running lightsyes
2 front headrestsyes
Front center 3-point beltyes
Engine immobilizeryes
In-Car Entertainment
In-Car Entertainment
AM/FM stereoyes
2 total speakersyes
USB connectionyes
USB with external media controlyes
Speed sensitive volume controlyes
Power Feature
Power Feature
Heated mirrorsyes
Comfort & Convenience
Comfort & Convenience
Tilt-adjustable steering wheelyes
Power steeringyes
Rear view camerayes
Front cupholdersyes
Front door pocketsyes
Single zone front air conditioningyes
Instrumentation
Instrumentation
Trip computeryes
Tachometeryes
Clockyes
Tires & Wheels
Tires & Wheels
Painted steel wheelsyes
Partial wheel coversyes
17 in. wheelsyes
All season tiresyes
LT235/80R17 tiresyes
Fullsize non-matching spare tireyes
Underbody mounted spare tireyes
Warranty
Warranty
Basic3 yr./ 36,000 mi.
Drivetrain5 yr./ 60,000 mi.
Rust6 yr./ 100,000 mi.
Roadside5 yr./ 60,000 mi.
Mechanical Options
Mechanical Options
Trailering Wiring Provisions +$35
Duramax 6.6L Turbo-Diesel V8 Engine +$9,890
Engine Block Heater +$100
Auxiliary Battery +$135
Power Take-Off (Late Availability) +$995
Heavy Duty Front Spring Package +$45
Integrated Trailer Brake Controller +$275
Underbody Shield +$150
Dual Alternators +$380
220 Amp Alternator +$150
High Idle Switch +$200
Gooseneck/5th Wheel Package +$1,365
Gooseneck Hitch Packageyes
Packages
Packages
WT Convenience Package +$1,825
WT Convenience Package w/Pickup Bed Delete +$1,675
Safety & Security Options
Safety & Security Options
WT Safety Package +$1,090
Interior Options
Interior Options
Color-Keyed Carpet Floor Covering w/Rubberized Vinyl Floor Mats +$100
OnStar and Chevrolet Connected Services Capable +$175
Cruise Control +$225
All-Weather Floor Liners +$120
120-Volt Instrument Panel Power Outlet +$225
Exterior Options
Exterior Options
Black Work Step +$415
4" Black - Round Assist Steps +$650
Pickup Box Delete -$1,155
Chevytec Spray-On Bed Liner +$545
Chrome Rear Bumper +$100
Vertical Outside Trailering Mirrors +$720
LED Cargo Area Lighting +$125
Front License Plate Kit +$0
Electric Rear-Window Defogger +$225
LT235/80R17E All-Terrain Blackwall Tires +$200
Chrome Front Bumper +$100
Deep-Tinted Glass +$100
Polished Exhaust Tip +$150
4" Chromed - Round Assist Steps +$650
Dark Essentials Package +$375
Black Front BowTie Emblem +$125
6" Rectangular Black Tubular Assist Steps +$650
LT235/80R17E All-Terrain Spare Tires +$380
