Used 2012 Ford Expedition EL XLT Specs & Features
| Overview | Starting MSRP $44,750 |
|---|---|
| Engine Type | Flex-fuel (FFV) |
| Transmission | 6-speed automatic |
| Drive Type | Four wheel drive |
| Cylinders | V8 |
| Total Seating | 8 |
| Basic Warranty | 3 yr./ 36,000 mi. |
| Fuel & MPG | |
|---|---|
| Fuel type | Flex-fuel (unleaded/E85) |
| EPA city/highway MPG | 13/18 MPG |
| EPA combined MPG | 15 MPG |
| Range in miles (city/hwy) | 435.5/603.0 mi. |
| Fuel tank capacity | 33.5 gal. |
| Engine | |
|---|---|
| Base engine size | 5.4 L |
| Cylinders | V8 |
| Base engine type | Flex-fuel (FFV) |
| Horsepower | 310 hp @ 5,100 rpm |
| Torque | 365 lb-ft @ 3,600 rpm |
| Valves | 24 |
| Cam type | Single overhead cam (SOHC) |
| Valve timing | Variable |
| Towing & Hauling | |
|---|---|
| Max Towing Capacity | 8,700 lbs. |
| Max Payload Capacity | 1,530 lbs. |
| Drivetrain | |
|---|---|
| Transmission | 6-speed automatic |
| Drive type | Four wheel drive |
| On demand 4WD | Standard |
| Electronic hi-lo gear selection | Standard |
| Automatic locking hubs | Standard |
| Mechanical center differential | Standard |
| Center locking differential | Standard |
| Suspension | |
|---|---|
| Four-wheel independent suspension | Standard |
| Short and long arm front suspension | Standard |
| Front and rear stabilizer bar | Standard |
| Multi-link rear suspension | Standard |
| Dimensions | |
|---|---|
| Length | 221.3 in. |
| Overall width without mirrors | 78.8 in. |
| Height | 78.3 in. |
| Wheelbase | 131.0 in. |
| Front track | 67.0 in. |
| Rear track | 67.2 in. |
| Cargo capacity, all seats in place | 42.6 cu.ft. |
| Maximum cargo capacity | 130.8 cu.ft. |
| Turning circle | 43.9 ft. |
| Ground clearance | 8.7 in. |
| Angle of approach | 24.1 degrees |
| Angle of departure | 20.9 degrees |
| Curb weight | 6,078 lbs. |
| Maximum towing capacity | 8,700 lbs. |
| Maximum payload | 1,530 lbs. |
| Country of final assembly | United States |
| Colors | |
|---|---|
| Exterior Colors |
|
| Interior Colors |
|
| Front Seat Dimensions | |
|---|---|
| Front head room | 39.5 in. |
| Front leg room | 41.1 in. |
| Front shoulder room | 63.2 in. |
| Front hip room | 60.2 in. |
| Cloth | Standard |
| Bucket front seats | Standard |
| 6-way power driver seat | Standard |
| 2-way manual driver seat adjustments | Standard |
| Height adjustable driver seat | Standard |
| Driver seat with manual adjustable lumbar support | Standard |
| 4-way manual passenger seat adjustment | Standard |
| Rear Seat Dimensions | |
|---|---|
| Rear head room | 39.7 in. |
| Rear leg room | 39.1 in. |
| Rear shoulder room | 63.7 in. |
| Rear hip room | 59.9 in. |
| Split-folding rear seatback | Standard |
| Reclining rear seats | Standard |
| Manual folding bench third row seats | Standard |
| Safety | |
|---|---|
| Post-collision safety system | Standard |
| Dual front side-mounted airbags | Standard |
| Front, rear and third row head airbags | Standard |
| Passenger airbag occupant sensing deactivation | Standard |
| Stability control | Standard |
| Traction control | Standard |
| Child seat anchors | Standard |
| Rear door child safety locks | Standard |
| 4-wheel ABS | Standard |
| Front and rear ventilated disc brakes | Standard |
| Electronic brakeforce distribution | Standard |
| Tire pressure monitoring | Standard |
| Dusk sensing headlamps | Standard |
| Auto delay off headlamps | Standard |
| Front fog/driving lights | Standard |
| 2 front headrests | Standard |
| Front multi-adjustable headrests | Standard |
| 2 rear headrests | Standard |
| Rear height adjustable headrests | Standard |
| Rear center 3-point belt | Standard |
| Front seatbelt pretensioners | Standard |
| Remote anti-theft alarm system | Standard |
| Engine immobilizer | Standard |
| In-Car Entertainment | |
|---|---|
| AM/FM stereo | Standard |
| 160-watt audio output | Standard |
| 6 total speakers | Standard |
| 1 subwoofer(s) | Standard |
| USB connection | Standard |
| Auxiliary audio input and USB with external media control | Standard |
| Satellite radio satellite radio | Standard |
| 6 months of provided satellite radio service | Standard |
| Radio data system | Standard |
| Adjustable speed sensitive volume control | Standard |
| Separate rear audio | Standard |
| Element antenna | Standard |
| Power Feature | |
|---|---|
| 1 one-touch power windows | Standard |
| Digital keypad power door locks | Standard |
| Power mirrors | Standard |
| Heated mirrors | Standard |
| Comfort & Convenience | |
|---|---|
| Tilt-adjustable steering wheel | Standard |
| Audio and cruise controls on steering wheel | Standard |
| Speed-proportional power steering | Standard |
| Rear parking sensors | Standard |
| 12V rear and 12V cargo area power outlet(s) | Standard |
| Cruise control | Standard |
| Adjustable pedals | Standard |
| Universal remote transmitter (for garage door, security system, etc.) | Standard |
| Front, rear and 3rd row cupholders | Standard |
| Front and rear door pockets | Standard |
| Overhead console with storage | Standard |
| Front seatback storage | Standard |
| Retained accessory power | Standard |
| Leather steering wheel | Standard |
| Dual zone air conditioning | Standard |
| Rear ventilation ducts | Standard |
| Dual illuminating vanity mirrors | Standard |
| Electrochromatic inside rearview mirror | Standard |
| Rear floor mats | Standard |
| Cargo area light | Standard |
| Simulated alloy trim on shift knob | Standard |
| Front reading lights | Standard |
| Instrumentation | |
|---|---|
| Trip computer | Standard |
| Compass | Standard |
| External temperature display | Standard |
| Tachometer | Standard |
| Clock | Standard |
| Low fuel level warning | Standard |
| Tires & Wheels | |
|---|---|
| Alloy wheels | Standard |
| 18 x 8.5 in. wheels | Standard |
| All terrain tires | Standard |
| P275/65R18 tires | Standard |
| Steel spare wheel | Standard |
| Fullsize non-matching spare tire | Standard |
| Underbody mounted spare tire | Standard |
| Telematics | |
|---|---|
| Airbag Deployment Notification | Standard |
| Destination guidance (also Turn-by-Turn Navigation) | Standard |
| Destination Download | Standard |
| Mobile Internet (Browser) | Standard |
| Warranty | |
|---|---|
| Basic | 3 yr./ 36,000 mi. |
| Drivetrain | 5 yr./ 60,000 mi. |
| Rust | 5 yr./ unlimited mi. |
| Roadside assistance | 5 yr./ 60,000 mi. |
| Mechanical Options | |
|---|---|
| Engine Block Heater | +$0 |
| PowerCode Remote Start | +$345 |
| Air Suspension | +$485 |
| Packages | |
|---|---|
| Sport Appearance Package | +$495 |
| Heavy Duty Trailer Tow Package | +$395 |
| Equipment Group 202A | +$5,610 |
| Equipment Group 203A | +$5,855 |
| Leather Seating Package | +$2,265 |
| Equipment Group 200A | +$0 |
| Equipment Group 201A | +$4,425 |
| Interior Options | |
|---|---|
| Voice-Activated Navigation System w/HD Radio | +$2,105 |
| 1st and 2nd Row Rubber Floormats | +$75 |
| Leather 2nd Row Captain's Chairs | +$795 |
| Invision Headrest Rear Seat DVD Entertainment System | +$1,995 |
| Climate Controlled Heated and Cooled Front Seats | +$790 |
| Heated 2nd Row Seats | +$395 |
| Exterior Options | |
|---|---|
| Power Moonroof | +$995 |
| 17" Aluminum Wheels | -$395 |
| Front License Plate Bracket | +$0 |
| Power Running Boards | +$995 |
