Used 2019 Mercedes-Benz Sprinter 3500XD 170" WB Cargo - Specs & Features

More about the 2019 Sprinter

Starting MSRP

$57,390

Overview

Diesel

Drive Type	four wheel drive
Total Seating	2
Cargo Capacity	430.1 cu.ft.
Curb Weight	6,074 lbs.
Basic Warranty	3 yr./ 36,000 mi.
Country of final assembly	Germany/United States

Fuel & MPG

Fuel type	Diesel fuel
Range in miles (city/hwy)	0/0 mi.
Fuel tank capacity	24.5 gal.

2019 Mercedes-Benz Sprinter for sale near you

3 of 388 listings

2500 170" WB Crew Diesel Passenger Van w/High Roof
MSRP: $47,995
12 mi away
Base Diesel
MSRP: $26,995
106 mi away
Base Diesel
MSRP: $24,999
115 mi away

Base Diesel
MSRP: $27,995
115 mi away
Diesel
MSRP: $34,999
116 mi away
Diesel
MSRP: $29,999
116 mi away
Base Diesel
MSRP: $27,999
119 mi away
2500 144" WB Crew Diesel Passenger Van w/High Roof
MSRP: $36,912
123 mi away
2500 144" WB Passenger Diesel Passenger Van w/High Roof
MSRP: $49,999
128 mi away

See all 388 listings

Engine

Base engine size	3.0 L
Cylinders	V6
Base engine type	Diesel

Horsepower	188 hp @ 3,800 rpm
Torque	325 lb-ft @ 1,400 rpm
Valves	24
Cam type	Double overhead cam (DOHC)
Direct injection (diesel)	Standard

Towing & Hauling

Max Towing Capacity	7,500 lbs.
Max Payload Capacity	4,956 lbs.

Drivetrain

Transmission	7-speed shiftable automatic
Drive type	Four wheel drive
On demand 4WD	Standard

Electronic hi-lo gear selection	Standard
Automatic locking hubs	Standard

Suspension

Front independent suspension	Standard
Front and rear stabilizer bar	Standard

Dimensions

Length	274.3 in.
Overall width with mirrors	95.5 in.
Overall width without mirrors	79.5 in.

Height	110.9 in.
Wheelbase	170.0 in.
Cargo capacity, all seats in place	430.1 cu.ft.
Maximum cargo capacity	430.1 cu.ft.
Turning circle	50.2 ft.
Ground clearance	8.2 in.
Curb weight	6,074 lbs.
Maximum towing capacity	7,500 lbs.
Maximum payload	4,956 lbs.
Gross weight	11,030 lbs.
Country of final assembly	Germany/United States

Colors

Exterior Colors	Jet Black Grey White Steel Blue Jupiter Red Silver Grey Pebble Grey Cavansite Blue Metallic Vanda Blue Arctic White Tenorite Grey Metallic Velvet Red Stone Grey Obsidian Black Metallic Sunset Red Calcite Yellow Black Blue Graphite Grey Selenite Grey Metallic Iridium Silver Brilliant Blue Blue Grey Aqua Green
Interior Colors	Maturin Black, cloth Black, leatherette Caluma Black, cloth

Front Seat Dimensions

Front head room	56.4 in.
Front leg room	38.9 in.
Front shoulder room	67.4 in.

Front hip room	63.7 in.
Cloth	Standard
Bucket front seats	Standard
4-way manual driver seat adjustments	Standard
4-way manual passenger seat adjustment	Standard

Safety

Post-collision safety system	Standard
Dual front side-mounted airbags	Standard
Front head airbags	Standard

Passenger airbag occupant sensing deactivation	Standard
Stability control	Standard
Traction control	Standard
4-wheel ABS	Standard
Brake drying	Standard
Ventilated front disc / solid rear disc brakes	Standard
Emergency braking assist	Standard
Tire pressure monitoring	Standard
Dusk sensing headlamps	Standard
Daytime running lights	Standard
Turn signal mirrors	Standard
2 front headrests	Standard
Front height adjustable headrests	Standard
Engine immobilizer	Standard

In-Car Entertainment

AM/FM stereo	Standard
80 watts stereo output	Standard
5 total speakers	Standard

USB connection	Standard
Auxiliary audio input	Standard
Speed sensitive volume control	Standard

Power Feature

Remote keyless power door locks	Standard
Heated mirrors	Standard

Comfort & Convenience

Keyless ignition	Standard
Tilt-adjustable steering wheel	Standard
Power steering	Standard

Rear view camera	Standard
Front cupholders	Standard
Front door pockets	Standard
Overhead console with storage	Standard
Single zone front air conditioning	Standard
Rear heater unit	Standard
Turn signal in mirrors	Standard

Instrumentation

External temperature display	Standard
Tachometer	Standard
Clock	Standard

Tires & Wheels

Steel wheels	Standard
16 x 5.5 in. wheels	Standard
All season tires	Standard

LT215/85R16 tires	Standard
Fullsize matching spare tire	Standard
Underbody mounted spare tire	Standard

Telematics

Emergency Service	Standard
Stolen Vehicle Tracking/Assistance	Standard
Roadside Assistance	Standard

Warranty

Basic	3 yr./ 36,000 mi.
Drivetrain	5 yr./ 100,000 mi.
Rust	3 yr./ unlimited mi.

Mechanical Options

Top Speed Limitation At 75 MPH	+$57
Speed Limitation 65mph	+$57
5kW Heater Booster	+$640

Bracket For Auxiliary AC Compressor	+$442
Axle Ratio 3.92	+$0
Spare Tire Carrier Deletion	+$0
Fuel-Fired Pre-Heater/Booster	+$1,057
Spare Wheel Deletion	-$108
Fuel Gauge	+$68
PTO at Front w/Bracket for Additional Alternator	+$442
Engine Oil Level Display at Cold Start	+$0
Downhill Speed Regulation for 4x4	+$55

Packages

Bench Seat Package	+$380
Premium Plus Package	+$2,530
Comfort Package	+$710

Comfort Plus Package	+$1,610
Heavy-Duty Cargo Protection Package	+$1,940
Exterior Lighting Package	+$1,520
Cargo Convenience Package	+$650
Cargo Protection Package	+$1,060
Swivel Seat Package	+$546
Premium Package	+$1,240
Driver Convenience Package	+$1,140
Chrome Grille Package	+$270

Safety & Security Options

Optional Three-Button Keys	+$34
Blind Spot Assist	+$426
Parking Package	+$582

Security Alarm w/Interior Motion Sensor	+$553
Rear Backup Alarm	+$94
Deactivation Lamp Monitoring Failure	+$25
First Aid Kit	+$25
Emergency Flashlight	+$25

Interior Options

Additional DIN-Slot	+$77
Rear Window Defroster	+$240
Two Additional Masters Keys	+$115

Heated Front Passenger Seat	+$269
Heated Driver's Seat	+$269
Thermotronic Automatic Climate Control	+$320
Instrument Cluster with Color Display	+$136
Cruise Control	+$250
Comfort Overhead Control Panel	+$88
D-Ring Cargo Straps	+$77
Cargo Partition w/1 Window	+$317
Rear Cabin Heater and Vents	+$744
Front Center Overhead Storage Slot	+$99
Parametric Special Module (PSM)	+$300
Leather Steering Wheel	+$176
Cargo Partition	+$273
Electrically Heated Windshield	+$206
Interior Roof Rack	+$437
115V Socket	+$118
Omission of D-Rings	-$15
Charging Package, Dashboard	+$78
Active Distance Assist DISTRONIC	+$171
Light Motion Sensor For Load Compartment	+$51
Cab Rear Wall Liner	+$340
Cutoff Relay for Additional Battery	+$104
12V Power Outlet, Rear Compartment	+$87
Additional battery for Retrofit Consumers, Driver Seat Base	+$235
Pallet Support in Sliding Door Step	+$91
Additional Battery for Retrofit Consumers, Engine Compartment	+$235
Tray for Smartphones w/Wireless Charging	+$137
Navigation	+$683
Cargo Straps/Lashing Rails	+$98
Smartphone Cradle	+$68
Plastic Floor Covering	+$350
SiriusXM Satellite Radio	+$228
Lashing Rails, Floor-Level (Plus 4 Anchors)	+$327
Side Wall Paneling Waist Height PVC	+$302
Rear Air Conditioner Heavy-Duty	+$3,731
Wood Floor with 6 D-Rings	+$400
Air Conditioning Rear, Roof-Mounted	+$2,721
Storage Compartment above Cabin	+$176
Heat Insulation Rear Compartment	+$148
Heat Insulation Front Compartment	+$176
Fan - Electric Roof	+$378
Hinged Lid For Storage Compartment	+$88
Front Cigarette Lighter w/Ash Cup	+$37
Acoustic Package	+$82
Rear Heater Preparation	+$383
Remote Control for Auxiliary Heater	+$360
Half Height Load Compartment Trim	+$190
Upper Cargo Lashing Rails	+$393
Pre-Fitting For Shelving Unit	+$607
Cargo Lashing Rails On Waistline	+$262
Storage Compartment w/Net In Rear Doors	+$120
Side Wall Paneling Full Hardboard	+$420

Exterior Options

Rain Sensor	+$100
Fog Lamp with Cornering Light Function	+$188
Trailer Crossmember, 7,500 lbs	+$176

Painted Metallic Front & Rear Bumper	+$556
Wheel Chocks	+$36
Mounting Rails For Roof Rack	+$284
Fixed Sunroof For Rear Roof Section	+$318
Primed Side Moldings	+$345
Assist Handle For Sliding Door	+$30
Sliding Door Right Side Deletion	+$0
Sliding Left Door	+$885
Heated And Electrically Adjustable Exterior Mirrors	+$273
Assist Handle For Left Rear Door	+$30
Electric Sliding Step	+$1,014
Michelin Tires	+$0
AGM Battery 12V 92Ah	+$96
Two Stage Opening Sliding Door	+$78
Assist Handle For Right Rear Door	+$30
Windows in Rear Doors	+$88
Fixed Window In Left Sliding Door	+$137
Electrical Sliding Door Right	+$787
Electric Closing Assist Right Sliding Door (Soft Close)	+$317
Specially Requested Tires	+$96
Fixed Window, Center Right	+$207
Opening Limiter, Electrically Operated Sliding Door	+$114
Fixed Window, Center Left	+$207
Illuminated Exits	+$143
Step, Wide, at Rear End	+$292
Right Rear Door Badging Deletion	+$0
Rear Door Window w/Wash Wipers	+$405
Rear Doors, Opening to Side Wall	+$340
Grey Rear Door Step	+$176
Left Rear Door Badging Deletion	+$0
Multifunction Steering Wheel	+$137
Def Fluid Filler Cap - Lockable	+$25
Primed Front & Rear Bumpers	+$254
Half-Sided Step Rear (For Trailer Hitch)	+$96
Jet Black Painted Wheels	+$77
Electric Closing Assist Left Sliding Door (Soft Close)	+$317
Kumho Tires	+$0
M+S Tires	+$160
Misfueling Prevention for Diesel	+$46
Wheel House Covering	+$99
Arctic White Painted Wheels	+$77
Continental Tires	+$0
Fixed Window In Right Sliding Door	+$137
Protective Edge On Door Sill	+$67
