Used 2016 GMC Sierra 3500HD Regular Cab - Specs & Features

More about the 2016 Sierra 3500HD

Select a trim

Starting MSRP

$37,590

Overview

Drive Type	four wheel drive
Total Seating	3
Bed length	97.8 in.
Payload Capacity	4,617 lbs.
Towing Capacity	14,500 lbs.
Curb Weight	6,324 lbs.
Basic Warranty	3 yr./ 36,000 mi.
Country of final assembly	United States

Fuel & MPG

Fuel type	Flex-fuel (unleaded/E85)
Range in miles (city/hwy)	0/0 mi.
Fuel tank capacity	36.0 gal.

2016 GMC Sierra 3500HD for sale near you

3 of 121 listings

SLT Diesel
MSRP: $43,500
88 mi away
Base Regular Cab
MSRP: $16,995
96 mi away
Denali Diesel Crew Cab
MSRP: $46,635
100 mi away

Denali Diesel Crew Cab
MSRP: $41,252
120 mi away
SLT Diesel Crew Cab
MSRP: $49,990
175 mi away
SLE Diesel
MSRP: $19,900
196 mi away
Denali Diesel
MSRP: $45,250
200 mi away
Denali Diesel Crew Cab
MSRP: $50,344
228 mi away
SLT Diesel Crew Cab
MSRP: $35,900
279 mi away

See all 121 listings

Engine

Base engine size	6.0 L
Cylinders	V8
Base engine type	Flex-fuel (FFV)

Horsepower	360 hp @ 5,400 rpm
Torque	380 lb-ft @ 4,200 rpm
Valves	16
Cam type	Overhead valves (OHV)
Valve timing	Variable

Towing & Hauling

Max Towing Capacity	14,500 lbs.
Max Payload Capacity	4,617 lbs.

Drivetrain

Transmission	6-speed automatic
Drive type	Four wheel drive
Part time 4WD	Standard

Manual hi-lo gear selection	Standard
Automatic locking hubs	Standard
Rear locking differential	Standard

Incentives

See Offers Near Columbus, OH

Check out current offers on the GMC Sierra 2500HD

View Offers

GMC.com

Suspension

Front independent suspension	Standard
Stabilizer bar stabilizer bar	Standard

Dimensions

Length	224.4 in.
Overall width without mirrors	80.1 in.
Height	77.9 in.

Wheelbase	133.6 in.
Bed length	97.8 in.
Turning circle	45.9 ft.
Ground clearance	8.7 in.
Curb weight	6,324 lbs.
Maximum towing capacity	14,500 lbs.
Maximum payload	4,617 lbs.
Gross weight	10,700 lbs.
Country of final assembly	United States

Colors

Exterior Colors	Iridium Metallic Summit White Onyx Black Quicksilver Metallic Crimson Red Tintcoat Light Steel Gray Metallic Stone Blue Metallic Deep Garnet Metalllic Cardinal Red Mahogany Metallic
Interior Colors	Jet Black/Dark Ash, cloth Jet Black/Dark Ash, vinyl

Front Seat Dimensions

Front head room	42.4 in.
Front leg room	45.3 in.
Front shoulder room	66.0 in.

Front hip room	60.7 in.
Vinyl	Standard
40-20-40 split bench front seats	Standard
4-way manual driver seat adjustments	Standard
4-way manual passenger seat adjustment	Standard

Safety

Passenger airbag deactivation switch	Standard
Stability control	Standard
Traction control	Standard

Child seat anchors	Standard
4-wheel ABS	Standard
Front and rear ventilated disc brakes	Standard
Tire pressure monitoring	Standard
Dusk sensing headlamps	Standard
Auto delay off headlamps	Standard
Daytime running lights	Standard
2 front headrests	Standard
Front height adjustable headrests	Standard
Front center 3-point belt	Standard
Engine immobilizer	Standard

Build Your 2025 Sierra 2500HD

At a Glance:

2 Trims
$46,300starting MSRP

Build & Price GMC.com

*The Manufacturer’s Suggested Retail Price excludes destination freight charge, tax, title, license, dealer fees, and optional equipment. Dealer sets final price. Click here to see all GMC vehicles’ destination freight charges.

In-Car Entertainment

AM/FM stereo	Standard
4 total speakers	Standard
USB connection	Standard

Auxiliary audio input and USB with external media control	Standard
Memory card slot	Standard
Radio data system	Standard
Adjustable speed sensitive volume control	Standard
Mast antenna	Standard

Power Feature

Power door locks	Standard
Heated mirrors	Standard

Comfort & Convenience

Tilt-adjustable steering wheel	Standard
Cruise controls on steering wheel	Standard
Power steering	Standard

Cruise control	Standard
Front cupholders	Standard
Front door pockets	Standard
Single zone front air conditioning	Standard
Passenger vanity mirror	Standard

Instrumentation

Trip computer	Standard
Tachometer	Standard
Clock	Standard

Tires & Wheels

Painted steel wheels	Standard
Partial wheel covers	Standard
18 x 8.0 in. wheels	Standard

All season tires	Standard
LT265/70R E tires	Standard
Fullsize matching spare tire	Standard
Underbody mounted spare tire	Standard

Warranty

Basic	3 yr./ 36,000 mi.
Drivetrain	5 yr./ 60,000 mi.
Rust	6 yr./ 100,000 mi.

Roadside assistance	5 yr./ 60,000 mi.
Free maintenance	2 yr./ 24,000 mi.

Mechanical Options

Dual 150 Amp Alternators	+$380
Auxiliary Battery w/730 Cold-Cranking Amps	+$135
Winter Covers for Diesel Engine	+$55

Engine Block Heater	+$90
220 Amp Alternator	+$150
3.73 Axle Ratio	+$100
Integrated Trailer Brake Controller	+$275
Bi-Fuel Compressed Natural Gas (CNG) System	+$9,500
6.0L SFI Gas/CNG Compatible V8 Engine	+$0
Duramax 6.6L Turbodiesel V8 Engine	+$8,395
5th-Wheel Trailer Wiring Equipment	+$35
High Idle Switch	+$200

Packages

Sierra Convenience Package	+$1,190
Snow Plow Prep. Package	+$385
GMC Interior Protection Package	+$200

Sierra Convenience Package	+$1,555
Skid Plate Package	+$150

Safety & Security Options

Thorax and Head Curtain Side-Impact Air Bags	+$395

Interior Options

GMC WiFi	+$595
Color-Keyed Carpet Floor Covering and Rubberized Vinyl Floormats	+$100
Front All-Weather Floor Mats	+$90

OnStar	+$175
IntelliLink Audio System w/7" Diagonal Color Touch Screen	+$435
SiriusXM Satellite Radio	+$195
Upfitter Switches	+$125

Exterior Options

Polished Exhaust Tip	+$135
Hard Tri-Folding Tonneau w/Vinyl Cover	+$995
Wheel Locks	+$60

Front and Rear Molded Splash Guards	+$215
4" Round Chrome Tubular Assist Steps	+$585
LT265/70R18E All-Season Blackwall Spare Tire	+$360
Skid Resistant Bed Liner	+$395
Body Color Molded Splash Guards	+$315
Pickup Bed Delete	-$1,290
Bed Rug	+$560
6" Rectangular Tubular Chromed Assist Steps	+$650
Body Color Wheel Arch Moldings	+$700
Chrome Recovery Hooks	+$295
Cargo Box Retractable Side Assist Step	+$360
4" Round Black Tubular Assist Steps	+$530
Body-Colored Bodyside Moldings	+$180
Body-Colored Accented Grille	+$495
Smoked Amber Roof Marker Lamps	+$55
Roof-Mounted Lamp Provision	+$30
Rubber Bed Mat	+$155
Vinyl Tonneau Cover	+$585
Electric Rear-Window Defogger	+$175
Spray-On Bed Liner	+$475
Bed Net	+$60
Rear Bumper Delete	-$655
6" Black Rectangular Tubular Assist Steps	+$600
Soft Folding Tonneau Cover	+$625
LT265/70R18E All-Terrain Blackwall Tires	+$200
